3 & 2 Bedroom Units – Full Architectural, Structural & CAD Drawing Package

This Full Architectural, Structural & CAD Drawing Package for 3-bedroom and 2-bedroom units provides everything required for seamless project execution—from design approval to on-site construction. The package includes detailed architectural plans, comprehensive structural drawings, and editable CAD files prepared according to professional building and engineering standards.

The structural section outlines all mandatory construction guidelines. All drawings must be used together with relevant architectural, structural, and service plans, and any discrepancies must be immediately reported to the Engineer. Dimensions are provided in millimeters, and contractors must confirm all measurements on-site before work begins.

Unless stated otherwise, all structural concrete is specified as Class 20/20 (1:2:4 mix ratio). Reinforcement cover requirements include 50mm for foundations and substructure columns, 40mm for superstructure columns, 25mm for beams, and 20mm for slabs. Reinforcement steels comply with BS4449, while mesh reinforcement follows BS4483 standards. All laps should maintain a minimum length of 50 times the bar diameter, ensuring structural integrity throughout the project.

All reinforcement must be inspected and approved by the project Engineer before any concrete pour is carried out.

This package is ideal for developers, contractors, and homeowners seeking accurate, compliant, and ready-to-build designs complete with both schematic clarity and structural reliability.
