7 Bedroom Mansion Design – Full Architectural & Structural Drawings

This premium 7-bedroom mansion design is a fully detailed construction package ideal for residential development in Kenya. The plan includes ground floor, first floor, and roof terrace layouts, along with all elevations, sections, and structural details required for county approval and actual construction.

The ground floor layout features three spacious bedrooms, a modern lounge, dining area, kitchen, pantry, laundry, kitchen yard, entrance lobby, passage, wardrobes, and master bathroom.
The first floor includes an additional three bedrooms, balconies, lounge, dining space, pantry, laundry, and a smooth connection to the staircase and lobby.
At the roof level, the design provides a large terrace area and an extra seventh bedroom with WC/SH, offering excellent outdoor entertainment and relaxation spaces.

The package also includes detailed construction notes, window and door schedules, foundation details, septic tank design, soak pit drawings, site plan, and drainage layout prepared to engineering and county standards.

All elevations—North, South, East, and West—are clearly drawn to show exterior finishes, heights, roofing, and structural components. The structural sheets (S-01, S-02) fully outline reinforcement details, RC slabs, columns, beams, staircase, and other key load-bearing elements.

This plan comes with:
• Architectural drawings (floor plans, elevations, sections, roof plan)
• Structural drawings with reinforcement details
• Door & window schedules
• Septic tank & soak pit design
• Site plan
• Construction notes & specifications
• Editable CAD files for customization

This 7-bedroom mansion is designed for elegance, functionality, and long-term durability—perfect for personal residence, luxury development, or investment projects.
